HYPACK MAX & HYSWEEP

Description

HYPACK MAX & HYSWEEP is hydrographic software from HYPACK for data collection, processing and final products. The HYPACK software package provides tools to design, acquire and process survey data and to create final products, from survey planning to deliverable.

The HYPACK SURVEY program handles input from over 200 devices, including GPS, inertial systems, sub-bottom systems, single and dual frequency echosounders and magnetometers; sensor inputs also cover sidescan and velocity sensors. Survey planning covers line creation with support for worldwide geodesy models, and the real-time navigation display supports a remote helmsman and survey view. HYPACK processing tools provide data cleaning with both manual and automatic filters.

Tools for creating contours, computing volumes, creating sidescan mosaics and creating electronic charts (ENC) are part of the HYPACK package. The TIN MODEL program creates surface models, generates DXF contours, computes volume quantities and exports gridded XYZ or BAG surfaces. HYPACK supports both analog and digital sub-bottom systems and saves sub-bottom data to the SEG-Y format as a standard feature.

HYPLOT outputs smooth sheets to a printer or plotter or saves them to PDF or DXF, with a choice of borders, sheet options and a user-designed title block. The CLOUD program is used for data review and accepts HYPACK data, XYZ data or LAS files. HYPACK data files can be exported to XYZ, CAD, DXF and other formats.

Technical Specification

Software

HYPACK MAX & HYSWEEP

Application

Hydrographic data collection, processing and final products

Sensor inputs

Over 200 devices: GPS, inertial systems, single and dual frequency echosounders, sidescan, sub-bottom systems, magnetometers, velocity sensors

Survey planning

Line creation with support for worldwide geodesy models

Navigation

Real-time navigation display with support for remote helmsman and survey view

Data processing

Data cleaning with manual and automatic filters

Final products

Contours, volume computation, sidescan mosaic, electronic charts (ENC)

Included programs

SURVEY, TIN MODEL, HYPLOT, CLOUD

TIN MODEL

Surface models, DXF contours, volume quantities; export of gridded XYZ or BAG surfaces

Sub-bottom support

Analog and digital sub-bottom systems; data saved to SEG-Y (standard feature)

HYPLOT

Smooth sheets to printer or plotter, or saved to PDF or DXF; selectable borders and sheet options; custom title block

CLOUD

Data review of HYPACK data, XYZ data or LAS files

Export formats

XYZ, CAD, DXF and other formats
