QPS Qimera 2

Description

QPS Qimera 2 is multibeam data processing software from QPS for post-processing multibeam echosounder, positioning and motion data from hydrographic surveys. Qimera 2 is used for editing, filtering, gridding and product generation from a wide variety of point cloud formats, and the user can return to the original ping at any time.

Qimera 2 includes Qimera Live for "hands-off" near-real time data processing and gridding, and Cooperative Cleaning and Production Line Processing workflows that let multiple processors work on the same project simultaneously. Analysis tools in Qimera 2 include the Patch Test tool with auto-solve functions for multibeam calibration, the Wobble tool, time series editors and multiplots, the Cross Check tool and Extinction tests. Automated data cleaning uses the Spline, CUBE and Blocking filters, and the TU Delft sound speed inversion provides an automated, repeatable sound speed refraction algorithm with output for vetting and reporting.

Qimera 2 covers sonar processing for all major manufacturers on surface vessels, ROV, AUV and ASV, with dynamic refraction, motion and tide corrections, real-time dynamic surface editing with 3D visualisation, automated data import with automatically generated vessel files, and guided workflows. Outputs include BAG, XYZ, ASCII, GSF and S-57, and Qimera 2 integrates with Qinsy and Fledermaus.

Qimera Midwater (water-column processing for QINSy DB, Kongsberg ALL and KMALL, and Reson/Norbit S7K formats), backscatter processing and mosaicking via Fledermaus Geocoder Toolbox, and "Connected" S-57 feature management are add-ons (optional).

Technical Specification

Software

QPS Qimera 2

Function

Multibeam data processing; editing, filtering, gridding and product generation from a wide variety of point cloud formats

Input data

Multibeam echosounder, positioning and motion data

Sonar processing

All major manufacturers; surface vessels, ROV, AUV and ASV

Included tools

Qimera Live, Cooperative Cleaning, Patch test, Wobble analysis, Time Series Multiplots, Cross Check, Extinction test

Qimera Live

"Hands-off" near-real time data processing and gridding

Multi-processor workflows

Cooperative Cleaning and Production Line Processing; multiple processors on the same project simultaneously

Automated data import

Automatically generated vessel files

Guided workflows

Automated suggestions of the next logical user action

Processing state management

Correct sequence of post-processing actions with a single click

Corrections

Dynamic refraction, motion and tide corrections; beam decimation, sound velocity profiling, heave/roll filtering

Automated data cleaning

Spline filter, CUBE filter, Blocking filters

Surface editing

Real-time dynamic surface editing with 3D visualisation

Multibeam calibration

Patch Test tool with auto-solve functions

Time series editors and multiplots

Correlation of motion data streams with bathymetry

Cross check tool

Statistical analysis of cross line beam footprint values versus a main scheme surface, with plot exports for reporting

Wobble tool

Identification of errors in multibeam and motion sensor integration

Extinction tests

Outer extents a multibeam system can achieve

Sound speed

TU Delft sound speed inversion; automated, repeatable refraction algorithm with output for vetting and reporting

Product generation

Visualisation, gridding and data export in various formats

Output formats

Industry-standard outputs, e.g. BAG, XYZ, ASCII, GSF, S-57

Integration

Qinsy, Fledermaus

Project size

Large datasets; multi-day, multi-platform projects

Qimera Midwater

Water-column processing for QINSy DB, Kongsberg ALL and KMALL, and Reson/Norbit S7K formats (add-on, optional)

Backscatter processing

Seabed backscatter processing and mosaicking via Fledermaus Geocoder Toolbox (add-on, optional)

"Connected" S-57 feature management

S-57 feature creation and editing with linkages to bathymetry (add-on, optional)
