Trimble CenterPoint RTX Marine

Description

Trimble CenterPoint RTX Marine is a real-time GNSS correction service from Trimble that uses an absolute positioning technique to model and correct GNSS error sources, delivering centimetre-level accuracy via satellite or the internet. CenterPoint RTX Marine is a subscription-based service for marine survey and construction applications worldwide.

CenterPoint RTX Marine gives < 2 cm horizontal RMS and < 5 cm vertical RMS accuracy; achievable accuracy and initialisation time may vary with receiver and antenna, location, atmospheric activity, scintillation, GNSS constellation health and multipath, and accuracy may vary beyond 100 nautical miles from the coast. Convergence time is < 1 minute in Trimble RTX Fast regions (throughout North America and Europe), and worldwide < 3 minutes with Trimble ProPoint receivers or < 15 minutes with legacy receivers. Regional coverage is available up to 100 nautical miles from continental coastlines, and global coverage beyond 100 nautical miles.

CenterPoint RTX Marine corrections are delivered with redundancy via satellite or internet and use AES encryption for anti-spoofing protection. Trimble operates redundant network operations centres with around-the-clock monitoring, and a global network of reference stations uploads real-time GNSS data to these centres, which transmit corrections through separate upload links to geostationary Trimble RTX satellites; cloud servers also provide the correction stream via the internet. The service uses GPS, Galileo, GLONASS, BeiDou-II, BeiDou-III and QZSS signals, with constellation inclusion dependent on area and beam selection.

Compatible devices for CenterPoint RTX Marine include the Trimble R780 integrated receiver, the Trimble R750, MPS865, SPS855, BX992 and Next Gen MPS566 modular receivers, and Applanix POS MV hardware (BD992, BD982), with Rugged Zephyr 3, 540 AP and GA830 antennas recommended for modular receivers. Trimble Marine Construction and Applanix PosPac MMS are also listed as compatible. CenterPoint RTX Marine can be used alongside a base-rover RTK setup or rover-only RTK within an RTK-network footprint, or as rover-only positioning with the CenterPoint RTX Marine service.

Technical Specification

Service type

Real-time GNSS correction service (subscription-based)

Positioning technique

Absolute positioning technique; Precise Point Positioning corrections

Accuracy

< 2 cm horizontal RMS, < 5 cm vertical RMS (RMS performance based on repeatable in-field measurements; may vary beyond 100 nautical miles from the coast)

Regional coverage

Up to 100 nautical miles from continental coastlines (< 200 kilometers, as stated)

Global coverage

Beyond 100 nautical miles from continental coastlines (> 200 kilometers, as stated)

Convergence time (Trimble RTX Fast regions)

< 1 minute (throughout North America and Europe)

Convergence time (worldwide)

< 3 minutes with Trimble ProPoint receivers; < 15 minutes with legacy receivers

Delivery

Satellite or internet, with redundancy

Security

AES encryption for anti-spoofing protection

GPS signals

L1C/A, L2E, L2C, L5

Galileo signals

E1, E5 (E5AltBOC, E5A, E5B)

GLONASS signals

L1C/A, L2C/A E6 (as stated)

BeiDou-II signals

B1I, B2I, B3

BeiDou-III signals

B1C, B2A, B3, B1I

QZSS signals

L1C/A, L2C, L5

Constellation inclusion

Dependent on area and beam selection

Compatible integrated receivers

Trimble R780

Compatible modular receivers

Trimble R750, MPS865, SPS855, BX992, Next Gen MPS566

Compatible Applanix receivers

POS MV hardware (BD992, BD982)

Recommended antennas (modular receivers)

Rugged Zephyr 3, 540 AP, GA830

Compatible software

Trimble Marine Construction, Applanix PosPac MMS

Network

Redundant network operations centres with around-the-clock monitoring; global reference station network; geostationary Trimble RTX satellites; internet delivery via cloud servers (Fast/Regional models for North America and Europe, Global model as redundant source)

Configurations

Base-rover RTK; rover only within RTK-network footprint; rover only with CenterPoint RTX Marine service
